VFD AC Drives - VLT Sine-wave Filter MCC 101
VLT® Sine-wave Filter MCC 101 output filters are differential mode low-pass filters that suppress the switching frequency component from the drive and smooth out the phase-to-phase output voltage of the drive to become sinusoidal. This reduces the motor insulation stress and bearing currents.
- Specifications
- Voltage rating 3 x 200 – 500 V and 3 x 525 – 690 V
- Nominal current IN @ 50 Hz 2.5 - 800 A (500 V) 4.5 – 660 A (690 V)
- Ambient temperature -25° to 45°C without derating
- Maximum switching frequency, f 8 kHz
- Approvals CE, UL 508
